| Core Dim (H x W) | Overall (H x W) | Hose Locations | Hose Fittings | Fill Neck | Trans Cooler | Mounting Specs | Mounting Type | ||||||
| 16 3/8" x 17 1/4" | 21 1/2" x 19 5/8" | In - Passenger, Out - Passenger | In - 1 1/2", Out - 1 3/4" | Yes | 1/8-27 NPT | Vert - 9 7/8", Horizontal - 17 3/4" | Bracket Mount | ||||||
| APPLICATION | ENGINES | 3 Row Core Thickness | 3 Row Tank Thickness | ||||||||||
| 1962-1965 Ford Falcon | 3.3L 200ci L6, 3.6L 221ci V8, | B CORE 2 1/2" | 2 3/4" | ||||||||||
| 4.3L 260ci V8, 4.7L 289ci V8 | |||||||||||||
| 1964-1966 Ford Mustang | 4.3L 260ci V8, 4.7L 289ci V8 | ||||||||||||
| 1962-1965 Ford Ranchero | 4.3L 260ci V8, 4.7L 289ci V8 | ||||||||||||
| 1962-1965 Mercury Comet | 3.6L 221ci V8, 4.3L 260ci V8, | ||||||||||||
| 4.7L 289ci V8 | |||||||||||||
| For Econoline Application go to 6065LP | |||||||||||||
