Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
26 1/2" x 29 7/8" |
31 7/8" x 30
1/2" |
In - Driver, Out -
Passenger |
In - 1 3/4",
Out - 1 3/4" |
No |
3/8-18 NPT |
N/A |
Pins |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
2 Row Core Thickness |
2 Row Tank Thickness |
|
2000 - 2005
Ford Excursion |
6.8L 415ci V10, 7.3L 445ci V8 |
|
|
|
1 5/8" |
2 1/2" |
|
1999 - 2004
Ford F-250 Super Duty |
6.8L 415ci V10, 7.3L 445ci V8 |
|
|
|
|
|
|
1999 - 2004
Ford F-350 Super Duty |
6.8L 415ci V10, 7.3L 445ci V8 |
|
|
|
|
|
|
1998 - 2005
Ford F-450 |
6.8L 415ci V10 |
|
|
|
|
|
|
1999 - 2004
Ford F-450 Super Duty |
6.8L 415ci V10, 7.3L 445ci V8 |
|
|
|
|
|
|
1999 - 2004
Ford F-550 Super Duty |
6.8L 415ci V10, 7.3L 445ci V8 |
|
|
|
|
|
|
1999 - 2004
Ford F53 |
6.8L 415ci V10 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
