CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
Fill Neck
TRANS COOLER
MOUNTING TYPE
23 1/2 x 26 7/8
30 7/8 x 27 1/2
In - Passenger, Out - Driver
In - 1 3/8, Out - 1 3/8
Yes
1/4-18 NPT
Pin Mount
Applications
Engine
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
2004 - 2010 Nissan Titan
5.6L V8
2"
2 5/8
