CORE DIM (H x W)	OVERALL (H x W)	HOSE LOCATIONS	HOSE FITTINGS	FILL NECK	TRANS COOLER	MOUNTING TYPE
	17 1/2 x 18 1/4	19 1/8 x 25 1/2	In - Driver, Out - Passenger	In - 1 1/2, Out - 1 3/4	Yes	1/2-20 Straight Thread, Inverted Flare	Bracket Mount
	APPLICATION		ENGINES			3 ROW CORE THICKNESS	3 ROW TANK THICKNESS
	1987 - 2006 Jeep Wrangler YJ		Chevy Configuration			2 1/4"	2 3/8"
						4 ROW CORE THICKNESS	4 ROW TANK THICKNESS
						2 3/4"	3 1/8"
