Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
20 3/8" x 21 5/8" |
25 7/8" x 29 7/8" |
In - Off-Set Passenger, Out - Passenger |
In - 1 1/2", Out - 1 3/4" |
Yes |
1/8-27 NPT |
28 5/8" |
Brackets |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1970 -1971
Dodge D100 Pickup |
5.2L 318ci V8 |
|
|
|
2 1/4" |
Upper - 3 3/4", Lower - 2 1/2" |
|
1970 - 1971
Dodge D200 Pickup |
5.2L 318ci V8 |
|
|
|
|
|
|
1970 - 1971
Dodge D300 Pickup |
5.2L 318ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
