Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
15 1/2" x 25 1/2" |
21" x 28" |
In - Passenger, Out
- Passenger |
In - 1 1/2",
Out - 1 3/4" |
Yes |
1/2 20 Straight
Thread, Inverted Flare |
26 3/4" |
Bracket |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1964 - 1965 Chevrolet Chevelle |
4.6L 283ci V8, 5.3L
327ci V8 |
|
|
|
2 1/4" |
2 5/8" |
|
1964 - 1965 Chevrolet El Camino |
4.6L 283ci V8, 5.3L
327ci V8 |
|
|
|
|
|
|
1964
- 1965 Chevrolet Malibu |
4.6L 283ci V8, 5.3L
327ci V8, |
|
|
|
|
|
|
6.5L 396ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
