CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
FILL NECK |
TRANS COOLER |
MOUNTING TYPE |
| |
17 3/8 x 17 5/8 |
23 3/4 x 18 3/4 |
In - Driver, Out - Passenger |
In - 1 1/2, Out - 1 3/4 |
Yes |
No |
Saddle Mount |
| |
|
|
|
|
|
|
|
|
| |
APPLICATION |
ENGINES |
|
2 ROW CORE THICKNESS |
2 ROW TANK THICKNESS |
| |
1960 - 1966 Chevrolet C10 Panel |
3.8L 230ci L6, 3.9L 235ci L6, 4.1L 250ci L6 |
|
1 1/2" |
2" |
| |
1960 - 1966
Chevrolet C10 Pickup |
3.8L 230ci L6, 3.8L 235ci L6, 3.9L 235ci L6, 4.1L 250ci L6, 4.3L 261ci
L6, 4.8L 292ci L6 |
|
|
|
| |
1960 - 1966
Chevrolet C20 Pickup |
3.8L 230ci L6, 3.8L 235ci L6, 4.1L 250ci L6, 4.3L 261ci L6, 4.8L 292ci
L6 |
|
|
|
| |
1960 - 1966
Chevrolet C30 Panel |
3.8L 230ci L6, 3.9L 235ci L6, 4.1L 250ci L6 |
|
|
|
| |
1960 - 1966
Chevrolet C30 Pickup |
3.8L 230ci L6, 3.8L 235ci L6, 4.1L 250ci L6, 4.3L 261ci L6, 4.8L 292ci
L6 |
|
|
|
| |
1960 - 1966
Chevrolet K10 Pickup |
3.8L 230ci L6, 3.8L 235ci L6, 4.1L 250ci L6, 4.3L 261ci L6, 4.8L 292ci
L6 |
|
|
|
| |
1960 - 1966
Chevrolet K20 Pickup |
3.8L 230ci L6, 3.8L 235ci L6, 4.1L 250ci L6, 4.3L 261ci L6, 4.8L 292ci
L6 |
|
|
|
| |
1960 - 1966
Chevrolet Suburban |
3.8L 230ci L6, 3.8L 235ci L6, 4.1L 250ci L6, 4.3L 261ci L6, 4.8L 292ci
L6 |
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
