Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
20 3/4" x 19 1/4" |
26 3/4" x 23" |
In - Center, Out - Passenger |
In - 1 1/2", Out - 1 3/4" |
Yes |
1/2-20 Straight Thread, Inverted Flare |
|
Bracket |
|
|
|
|
|
|
|
|
|
|
APPLICATION |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1947 -
1954 Chevy C/K Series |
3.5L 217ci L6, 3.8L 235ci L6, |
|
|
|
2 1/2" |
2 3/4" |
|
4.3L 261ci L6 |
|
|
|
|
|
|
1947 -
1954 Chevy Suburban |
3.5L 217ci L6, 3.8L
235ci L6, |
|
|
|
|
|
|
4.3L 261ci L6 |
|
|
|
|
|
|
1947 -
1954 Chevy Panel Truck |
3.5L 217ci L6, 3.8L
235ci L6, |
|
|
4.3L 261ci L6 |
|
|
|
|
|
|
|
|
|
|
|
