CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

TRANS COOLER

MOUNTING TYPE

20 3/4 x 19 1/4

26 3/4 x 23

In - Center, Out - Passenger

In - 1 1/2, Out - 1 3/4

1/2-20 Straight Thread, Inverted Flare

Bracket Mount

APPLICATION

Engines

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

1947 - 1954 Chevy C/K Series

3.5L 217ci L6, 3.8L 235ci L6,

2 1/2"

2 3/4"

4.3L 261ci L6

1947 - 1954 Chevy Suburban

3.5L 217ci L6, 3.8L 235ci L6,

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

4.3L 261ci L6

1 1/2"

1947 - 1954 Chevy Panel Truck

3.5L 217ci L6, 3.8L 235ci L6,

4.3L 261ci L6

4 ROW CORE THICKNESS

4 ROW TANK THICKNESS

2 3/4"

3 1/8"
