Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 1/8" 21 5/8" |
23 1/4" x 23 5/8" |
In - Center, Out - Passenger |
In - 1 1/2" x Out - 1 3/4" |
Yes |
1/2-20 Straight Thread, Inverted Flare |
23 5/8" |
Brackets |
|
|
Application |
Engines |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1955 - 1957
Chevrolet Bel Air |
4.3L 265ci V8, 4.6L 283ci V8 |
|
2 1/2" |
3" |
|
1955 - 1957
Chevrolet Nomad |
4.3L 265ci V8, 4.6L 283ci V8 |
|
|
1955 - 1957
Chevrolet 150 Series |
4.3L 265ci V8, 4.6L 283ci V8 |
|
|
1955 - 1957
Chevrolet 210 Series |
4.3L 265ci V8, 4.6L 283ci V8 |
|
|
1957
Chevrolet Del Rey |
4.3L 265ci V8, 4.6L 283ci V8 |
|
|
|
|
|
|
|
|
|
|
|
