CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
FILL NECK
TRANS COOLER
MOUNTING TYPE
BRACKETS
18 3/4 x 25 1/2
24 1/4 x 29
In - Passenger, Out - Driver
In - 1 1/2, Out - 1 3/4
Yes
1/8-27 NPT
Bracket
28 1/2
APPLICATION
ENGINES
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
49 - 51 Mercury Car w/Ford Configuration
2 1/4"
Upper - 4 1/8", Lower - 2 3/4"
