CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
FILL NECK
TRANS COOLER
MOUNTING TYPE
23 5/8 x 16 3/8
29 5/8 x 21 1/8
In - Center, Out - Pasenger
In - 1 1/2, Out - 1 3/4
Yes
1/2-20 Straight Thread, Inverted Flare
Bracket Mount
APPLICATION
ENGINES
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
34-36 Chevy P/U Truck
V8 Conversion
2 1/4"
2 3/8"
4 ROW CORE THICKNESS
4 ROW TANK THICKNESS
3 1/8"
2 3/4"
