CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
FILL NECK
TRANS COOLER
MOUNTING TYPE
17 1/2 x 22 3/4
23 3/4 x 25 1/4
In - Passenger, Out - Driver
In - 1 3/4, Out - 1 3/4
Yes
1/2-20 Straight Thread, Inverted Flare
Saddle Mount
APPLICATION
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
Buick 1960-64
2 1/4"
2 3/4"
Does NOT fit the Riviera, Invicta, or La Sabre
2 ROW CORE THICKNESS
2 ROW TANK THICKNESS
1 1/2"
2 1/4"
4 ROW CORE THICKNESS
4 ROW TANK THICKNESS
2 3/4"
3 1/8"
