CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
FILL NECK
TRANS COOLER
MOUNTING TYPE
17 3/4 x 22 3/4
23 1/2 x 25 1/2
In - Driver, Out - Driver
In - 1 1/2, Out - 1 3/4
Yes
1/2-20 Straight Thread, Inverted Flare
Saddle Mount
APPLICATION
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
Olds Starfire 61-62
2 1/4"
2 3/4"
Olds "88 " 61-62
Cadillac 1961-65
2 ROW CORE THICKNESS
2 ROW TANK THICKNESS
1 1/2"
2 3/4"
4 ROW CORE THICKNESS
4 ROW TANK THICKNESS
2 3/4"
3 1/8"
