Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
18 1/4" x 20 1/4" |
23" x 25 3/4" |
In - Passenger, Out - Driver |
In - 1 1/4", Out - 1 1/2" |
Yes |
5/8-18 Straight Thread, Inverted Flare |
24 3/8" |
Bracket |
|
|
|
|
|
|
|
|
|
|
APPLICATION |
ENGINES |
|
|
|
1 Row Core Thickness |
1 Row Tank Thickness |
|
1987 - 2006
Jeep Wrangler YJ |
2.4 148 L4, 4.0 242 L6, 4.2 258 L6 |
|
|
|
2 3/8" |
2 3/8" |
|
1997 - 2004
Jeep Wrangler |
2.4 148 L4, 4.0 242 L6 |
|
|
|
|
|
|
2006 Jeep
TJ |
2.4 148 L4, 4.0 242 L6 |
|
|
|
|
|
|
Note: Bar & Plate Version For Jeep
Wrangler |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
