CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
FILL NECK |
Engine Oil Cooler |
TRANS COOLER |
MOUNTING TYPE |
| |
14 7/8" x 26 1/4" |
17 5/8" x 32" |
In - Driver, Out - Passenger |
In - 1 3/8, Out - 1 1/2 |
Yes |
Metric 20-1.5 |
1/2-20 Straight Thread,
Inverted Flare |
Pin Mount |
| |
|
|
|
|
|
|
|
|
| |
APPLICATION |
ENGINES |
|
|
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
| |
Chevy/GMC S/T Series Pickups/Blazers-1996-2005 |
4.3l 262 V6 |
|
|
|
2 1/4" |
2 5/8" |
| |
Chevy/GMC Blazers/Jimmy-1996-2005 |
4.3l 262 V6 |
|
|
|
|
|
| |
Olds Bravada-1996-2001 |
4.3l 262 V6 |
|
|
|
|
|
| |
S10 V8 Conversion 86-2005 |
Chevy Conversion |
|
|
|
|
|
| |
Isuzu Hombre-1997-2000 |
4.3l 262 V6 |
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
