Core Dim (H x W)	Overall (H x W)	Hose Locations	Hose Fittings	Fill Neck	Bracket	Mounting Type
	19 5/8 x 34	21 5/8 x 40 5/8	In - Driver, Out - Passenger	In - 1 5/16, Out - 1 9/16	Yes	N/A	Saddle Mount
	Application		Engines			Trans Cooler	Engine Oil Cooler
	1994 - 2000 C/K Series Pick Up W/O Raised Fill Neck		7.4L/454 ci V8			1/2-20	M20 x 1.5
	1994 - 1999 Suburban		7.4L/454 ci V8			5/8-18 Adapter	3/4-18 Adapter
						3 Row Core Thickness	3 Row Tank Thickness
						2 1/4"	2 1/2"
