CORE DIM
(H x W)
OVERALL
(H x W)
HOSE LOCATIONS
HOSE FITTINGS
Fill Neck
TRANS COOLER
MOUNTING TYPE
15 1/2" x 25"
21" x 25 1/2"
In - Driver, Out - Passenger
In - 1 1/2, Out - 1 3/4
Yes
1/2-20 Straight Thread, Inverted Flare
Saddle
APPLICATION
ENGINES
2 ROW CORE THICKNESS
2 ROW TANK THICKNESS
1965-67 Tempest
5.3 V8
1 1/2"
2 1/2"
1965-67 GTO
5.3 V8
1965-67 Lemans
5.3 V8
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
2 1/4"
2 1/2"
4 ROW CORE THICKNESS
4 ROW TANK THICKNESS
2 3/4"
3 1/8"
