CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

FILL NECK

TRANS COOLER

MOUNTING TYPE

15 3/4 x 25

21 3/4 x 25 1/2

In - Driver, Out - Passenger

In - 1 1/2, Out - 1 3/4

Yes

1/2-20 Straight Thread, Inverted Flare

Saddle Mount

APPLICATION

ENGINES

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

Tempest 1965-67

5.3 V8

1 1/2"

2 1/2"

GTO 1965-67

5.3 V8

Lemans 1965-67

5.3 V8

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

2 1/4"

2 1/2"
