Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 3/8" x 24 3/4" |
22 5/8" x 28
5/8" |
In - Driver, Out -
Passenger |
In - 1 1/2",
Out - 1 3/4" |
Yes |
1/2-20 Straight
Thread, Inverted Flare |
27" |
Bracket |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1969-1970 Chevrolet Bel Air |
4.1L 250ci L6, 5.3L
327ci V8, |
|
|
|
2 1/4" |
2 1/2" |
|
5.4L 327ci V8, 5.7L 350ci V8, |
|
|
|
|
|
|
6.6L 400ci V8 |
|
|
|
|
|
|
1969 Chevrolet Biscayne |
4.1L 250ci L6, 5.3L 327ci V8, |
|
|
|
|
|
|
5.4L 327ci V8, 5.7L 350ci V8 |
|
|
|
|
|
|
1969 Chevrolet Caprice |
4.1L 250ci L6, 5.0L 307ci V8, |
|
|
|
|
|
|
5.3L 327ci V8, 5.4L 327ci V8, |
|
|
|
|
|
|
5.7L 350ci V8 |
|
|
|
|
|
|
1969 Chevrolet Impala |
4.1L 250ci L6, 5.0L 307ci V8, |
|
|
|
|
|
|
5.3L 327ci V8, 5.4L 327ci V8, |
|
|
|
|
|
|
5.7L 350ci V8 |
|
|
|
|
|
|
Note: Designed for vehicles with A/C |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
