Core Dim (H x W)
Overall (H x W)
Hose Locations
Hose Fittings
Fill Neck
Trans Cooler
Mounting Specs
Mounting Type
19 3/4" x 18 7/8"
25 5/8" x 23 1/8"
In - Driver, Out - Passenger
In - 1 1/2", Out - 1 3/4"
Yes
1/4-18 NPT
21 3/4"
Brackets
Application
Engines
3 Row Core Thickness
3 Row Tank Thickness
1958 Chevrolet Bel Air
5.7L 348ci V8
2 1/4"
Upper - 3 1/8", Lower - 2 5/8"
1958 Cherolet Biscayne
5.7L 348ci V8
1958 Chevrolet Brookwood
5.7L 348ci V8
1958 Chevrolet Del Ray
5.7L 348ci V8
1958 Chevrolet Impala
5.7L 348ci V8
1958 Chevrolet Nomad
5.7L 348ci V8
1958 Chevrolet Yeoman
5.7L 348ci V8
