Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 1/8" x 21 1/8" |
22 7/8" x 25 3/4" |
In - Driver, Out - Passenger |
In - 1 1/2", Out - 1 3/4" |
Yes |
1/2-20 UNF Male |
24 1/2" |
Brackets |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1966 - 1969
Dodge Charger |
5.2L 318ci V8, 5.9L 361ci V8 |
|
|
2 1/4" |
Upper - 3 3/8", Lower 2 1/2" |
|
1965 - 1969
Dodge Coronet |
5.2L 318ci V8, 5.9L 361ci V8 |
|
|
|
|
|
1963 - 1967
Plymouth Belvedere |
5.2L 318ci V8, 5.9L 361ci V8 |
|
|
|
|
|
1963 - 1967
Plymouth Fury |
5.2L 318ci V8, 5.9L 361ci V8 |
|
|
|
|
|
1965 - 1967
Plymouth Satalite |
5.2L 318ci V8, 5.9L 361ci V8 |
|
|
|
|
|
1963 - 1964
Plymouth Savoy |
5.2L 318ci V8, 5.9L 361ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
