CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

TRANS COOLER

FILL NECK

MOUNTING TYPE

BRACKET SPECS

14 1/2 X 15 1/4

18 3/4 X 18 1/4

In - Passenger, Out - Driver

In - 1 3/8, Out - 1 3/8

No

Yes

Bracket Mount

Vert - 7 7/8  Horizontal - 17

APPLICATION

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

Datsun Fairlady 1600

1 1/2"

2 1/2"

1965-70

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

B CORE  2 1/2"

2 3/4"
