CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
Fill Neck
TRANS COOLER
MOUNTING TYPE
BRACKET SPECS
16 1/8 x 25 3/8
22 3/8 x 27 5/8
In - Off-Set Passenger, Out - Passenger
In - 1 1/2, Out - 1 1/2
No
Metric 12-1.25
Upper - Tabs, Lower - Pins
Tabs - Horizontal- 26 1/2"
APPLICATION
ENGINES
2 ROW CORE THICKNESS
2 ROW TANK THICKNESS
Nissan 300ZX 1984-89
3.0 V6 Turbo/Non Turbo
1 1/2"
2 1/2"
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
2"
2 1/2"
