Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
18 7/8" x 28 1/4" |
21 1/8" x 33
3/4" |
In - Driver, Out -
Passenger |
In - 1 3/8",
Out - 1 5/8" |
Yes |
1/2-20 Straight
Thread, Inverted Flare |
N/A |
Saddle |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1973 - 1987 Chevrolet Blazer |
5.7L 350ci V8, 7.4L 454ci V8 |
|
|
2 1/4" |
3 1/8" |
|
1973 - 1986 Chevrolet C Series |
5.7L 350ci V8, 7.4L 454ci V8 |
|
|
|
|
|
1973 - 1986 Chevrolet K Series |
5.7L 350ci V8, 7.4L 454ci V8 |
|
|
|
|
|
1987 Chevrolet R Series |
5.7L 350ci V8, 7.4L 454ci V8 |
|
|
|
|
|
1987 Chevrolet V Series |
5.7L 350ci V8, 7.4L 454ci V8 |
|
|
|
|
|
1973 - 1986 GMC C Series |
5.7L 350ci V8, 7.4L 454ci V8 |
|
|
|
|
|
1973 - 1986 GMC Jimmy |
5.7L 350ci V8, 7.4L 454ci V8 |
|
|
|
|
|
1973 - 1986 GMC K Series |
5.7L 350ci V8, 7.4L 454ci V8 |
|
|
|
|
|
1987 GMC R Series |
5.7L 350ci V8, 7.4L 454ci V8 |
|
|
|
|
|
1987 GMC V Series |
5.7L 350ci V8, 7.4L 454ci V8 |
|
|
|
|
|
NOTE: The 4x2/4x4 designation
was C/K, respectively, through 1986. It was changed to R/V for the 1987 model
year for these vehicles, though they may still be commonly referred to as C/K
by owners. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
