CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

TRANS COOLER

MOUNTING TYPE

17 x 26 1/4

18 3/4 x 32 1/4

In - Driver / Out -Pass

In - 1 3/8 Out 1 -1/2

1/2-20 Straight Thread, Inverted Flare

SADDLE MOUNT

APPLICATION

ENGINES

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

Chevy Corvette - 1977-83

350ci V8

1 1/2"

2 1/2"

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

B CORE 2 1/2"

2 3/4"

4 ROW CORE THICKNESS

4 ROW TANK THICKNESS

2 3/4"
