Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Bracket |
Mounting Type |
|
17 1/4 x 28 1/4 |
20 1/4 x 33 7/8 |
In - Driver, Out - Passenger |
In - 1 5/16, Out - 1 9/16 |
Yes |
N/A |
Saddle |
|
|
Application |
Engines |
|
Trans Cooler |
Engine Oil Cooler |
|
1988 - 1994
C/K Series Pickup |
5.7L/350ci V8; 5.0L/305ci V8 |
|
1/2-20 Straight Thread, Inverted Flare |
M20 x 1.5 |
|
1995 C/K
Series Pickup |
5.0L/305ci V8 |
|
5/8 - 18 Adapter |
Quick Disconnect Adapter |
|
1992 - 1993
Chevy Suburban |
5.7L/350ci V8 |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
2 1/4" |
2 1/2" |
|
|
|
|
|
|
|
|
|
|
