CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
TRANS COOLER
MOUNTING TYPE
BRACKET SPECS
15 5/8 x 24
22 x 27
In - Passenger, Out - Driver
In - 1 1/2, Out - 1 1/2
1/8-27 NPT
Bracket Mount
Vert - 7 Horizontal- 25 3/4
APPLICATION
ENGINES
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
Jeep CJ Series 1970-85
3.8/4.2/5.0 L6,V8
2 1/4"
2 3/4"
4 ROW CORE THICKNESS
4 ROW TANK THICKNESS
2 3/4"
3 1/8"
