CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

TRANS COOLER

MOUNTING TYPE

17 x 27 1/2

18 3/8 x 32 1/2

In - Driver, Out - Passenger

In - 1 1/2, Out - 1 1/2

1/2-20 Straight Thread, Inverted Flare

Saddle Mount

APPLICATION

ENGINES

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

Firebird/Trans Am 1970-81

3.8/4.3/4.9/5.0/5.7/6.6, V6/V8

1 1/2"

2 1/2"

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

2 1/4"

2 1/2"
