CORE DIM (H x W)

OVERALL (H x W)

HOSE FITTINGS

HOSE LOCATIONS

Fill Neck

TRANS COOLER

MOUNTING TYPE

17" x 20 3/4"

19" x 27"

In - 1 1/2", Out - 1 1/2"

In - Driver, Out - Passenger

Yes

1/2-20 Straight Thread, Inverted Flare

Saddle Mount

APPLICATION

ENGINES

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

Buick Apollo - 1973-74

4.1l 250 L6

1 1/2"

2 1/2"

Buick Century -1977

5.0l 305 V8, 5.7l 350 V8

Buick Century - 1979-81

3.2l 196 V6, 3.8l 231 V6

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

Buick Le Sabre - 1965

4.9l 300 V8

2 1/4"

2 1/2"

Buick Le Sabre - 1980-85

3.8l 231 V6

Buick Skylark-1977-79

5.0l 305 V8

4 ROW CORE THICKNESS

4 ROW TANK THICKNESS

Buick Skylark-1965-69

3.7l 225 V6, 4.9l 300 V8, 6.6l 401 V8, 4.1l 250 L6

2 3/4"

3 1/8"

Buick Skylark-1967

6.6l 401 V8

Buick Regal - 1980-87

3.8l 231 V6, 4.1l 252 V6 (Non-Turbo)

Chevy Biscayne-1971-1972

4.1l 250 L6

Chevy Bel-Air - 1971-73

4.1l 250 L6, 5.7l 350 V8

Chevy Chevelle - 1968-71

4.1l 250 L6

Chevy Camaro-1972-1977

4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8, 5.0l 305 V8

Chevy Camaro - 1972-81

4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8, 5.0l 305 V8, 3.8l 229 V6, 3.8l 231 V6, 4.4l 267 V8

Chevy Caprice - 1980-86

3.8l 229 V6, 3.8l 231 V6, 4.3l 262 V6

Chevy Chevelle - 1972-73

4.1l 250 L6, 5.0l 307 V8

Chevy El Camino / Caballero - 1975-77

4.1l 250 L6

Chevy El Camino / Caballero - 1979-87

3.8l 231 V6, 3.8l 229 V6, 4.3l 262 V6

Chevy Impala - 1971 -73

4.1l 250 L6

Chevy Malibu - 1975-77

4.1l 250 L6

APPLICATION

ENGINES

Chevy Malibu - 1978-83

3.8l 231 V6, 3.8l 229 V6

Chevy Monte Carlo - 1972-73

5.7l 350 V8

Chevy Monte Carlo - 1979-88

3.8l 231 V6, 3.8l 229 V6, 4.3l 262 V6, 3.8l 231 V6,

Chevy Nova - 1968-69

3.7l 225 V6, 5.0l 307 V8, 5.7l 350 V8

Chevy Nova - 1972-79

4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8, 4.3l 262 V8

Chevy Nova - 1970-71

5.0l 307 V8, 5.7l 350 V8, 4.1l 250 L6

Chevy Nova - 1972-74

4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8

Olds 98 -1981-83

4.1l 252 V6

Olds Cutlass Calais - 1981-1983

3.8l 231 V6

Olds Cutlass - 1980-87

3.8l 231 V6,

Olds Cutlass Supreme - 1980-87

3.8l 231 V6

Olds Cutlass Cruiser - 1980-83

3.8l 231 V6

Olds Omega - 1973-79

4.1l 250 L6, 5.0l 305 V8

Olds Omega - 1973

4.1l 250 L6

Olds Delta 88/ Eighty Eight/ Royal -1979

3.8l 231 V6

Pontiac Bonneville - 1980-86

3.8l 231 V6, 4.1l 252 V6,4.3l 262 V6

Pontiac Catalina - 1980-81

3.8l 229 V6, 3.8l 231 V6

Pontiac Firebird / Trans Am - 1970-76

4.1l 250 L6

Pontiac Le Mans- 1972

4.1l 250 L6

Pontiac Le Mans- 1980-81

3.8l 229 V6, 3.8l 231 V6

APPLICATION

ENGINES

Pontiac Parisienne-1984-86

3.8l 231 V6, 4.3l 262 V6

Pontiac Phoenix-1978-79

5.0l 305 V8, 5.7l 350 V8

Pontiac Ventura-1972-76

4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8

Pontiac Ventura - 1972-74

4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8
