Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17" x 22 3/8" |
22 5/8" x 25" |
In - Driver, Out - Passenger |
In - 1 1/2", Out 1 3/4" |
Yes |
1/8-27 NPT |
23 5/8" |
Bracket |
|
|
APPLICATION |
ENGINES |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1970 - 1972
Plymouth Duster |
318, 340, 360 - Small Block V8 |
|
2 1/2" |
3" |
|
1970 - 1972
Plymouth Valiant |
318, 340, 360 - Small Block V8 |
|
|
1970 - 1972
Dodge Dart |
318, 340, 360 - Small Block V8 |
|
2 Row Core Thickness |
2 Row Tank Thickness |
|
1 5/8" |
3" |
|
|
|
|
|
|
|
|
|
|
