Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Bracket |
Mounting Type |
|
14 1/2" x 20 3/8" |
17 3/8" x 26 1/8" |
In - Driver, Out - Passenger |
In - 1 1/2", Out - 1 1/2" |
Yes |
1/2-20 Straight Thread, Inverted Flare |
N/A |
Saddle |
|
|
Application |
Engines |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1978 - 1980
Chevrolet Monza |
2.5L L4, 3.2L V6, 3.8L V6 |
|
2 1/4" |
2 3/4" |
|
1978 - 1980
Chevrolet Monza |
5.0L V8* |
|
|
1971 - 1977
Chevy Vega |
For V8 Swap |
|
|
*To use on Monza, power steering must be relocated. |
|
|
|
|
|
|
|
|
|
|
|
