CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
FILL NECK |
TRANS COOLER |
MOUNTING TYPE |
|
17 x 23 |
18 3/4 x 29 |
In-Passenger, Out-Passenger |
In/Out: -16ORB (Female) |
Yes |
No |
Saddle Mount |
|
|
|
|
|
|
|
|
|
|
|
APPLICATION |
ENGINES |
|
LS Engine Swap And Dual Pass for
All Engines Below |
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
Olds Omega - 1973-74 |
4.1 250 L6, 5.7 350 V8 |
|
|
2 1/4" |
2 3/8" |
|
Buick Apollo - 1973-74 |
5.7 350 V8 |
|
|
|
|
Pontiac Ventura - 1973-74 |
5.7 350 V8 |
|
|
|
|
Chevy Nova - 1973-74 |
5.0 307 V8, 5.7 350 V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
