CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
TRANS COOLER |
FILL NECK |
BRACKET SPECS |
MOUNTING TYPE |
|
16" x 24 3/8" |
21 3/4" x 27 3/8" |
In - Passenger, Out - Driver |
In - 1 1/2, Out -1 1/2 |
1/2-20 Straight Thread, Inverted Flare |
Yes |
On Grill Side |
Bracket Mount |
|
|
APPLICATION |
Engines |
|
2 ROW CORE THICKNESS |
2 ROW TANK THICKNESS |
|
AMC Hornet
1972 - 77 |
232ci 3.8l I6, 258ci 4.2l I6, 304 5.0l V8 |
|
1 5/8" |
2 1/2" |
|
AMC Gremlin
1972-76 |
232ci 3.8l I6, 258ci 4.2l I6, 304 5.0l V8 |
|
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
2 1/4" |
2 1/2" |
|
|
4 ROW CORE THICKNESS |
4 ROW TANK THICKNESS |
|
2 3/4 |
3 1/8 |
|
|
|
|
|
|
|
|
|
|
