Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
|
16 1/2" x 28" |
19 1/8" x 33 5/8" |
In - Passenger, Out - Driver |
In - 1 1/2", Out - 1 1/2" |
Yes |
1//8-27 NPT |
N/A |
Saddle Mount |
|
|
|
Application |
Engines |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
|
Ford Torino - 1972 - 76 |
5.0, 7.0, 302 V8 |
|
2 1/4" |
2 1/2" |
|
|
Ford Country Squire - 1972 - 76 |
7.5 460 V8 |
|
|
Ford Thunderbird 1972 - 79 |
5.0 302, 5.8 351, 6.6 400, 7.0 429, 7.5 460 V8 |
|
4 Row Core Thickness |
4 Row Tank Thickness |
|
|
Lincoln Mark V 1977 |
7.5 460 V8 |
|
2 3/4" |
3 1/8" |
|
|
Mercury Cougar/ XR7 1974 - 79 |
|
|
|
Ford LTD II 1977 - 79 |
5.0, 6.6, 5.8, 302, 400, 351 |
|
|
Mercury Montego 1972 - 76 |
|
|
|
Ford Ranchero - 1974 - 79 |
7.5 460, 5.0 302 v8 |
|
|
Lincoln Mark IV 1973 - 76 |
7.5 460 V8 |
|
|
Lincoln Continental 1973 |
7.5 460 V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
