CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
FILL NECK |
TRANS COOLER |
MOUNTING TYPE |
| |
17 7/8 x 26 |
20 x 31 5/8 |
In - Passenger, Out - Driver |
In - 1 1/2, Out - 1 1/2 |
Yes |
1/8-27 NPT |
Saddle Mount |
| |
|
|
|
|
|
|
|
| |
APPLICATION |
ENGINES |
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
| |
1970-71
MERCURY MONTEREY |
7.0 428/ 429ci V8 |
|
2 1/4" |
2 1/2" |
| |
1971-73
FORD MUSTANG |
7.0 429ci V8/ 5.0L 302ci V8 |
|
|
|
| |
1970-71
MERCURY MONTEGO |
7.0L/429 ci/V8 |
|
|
|
| |
1969-71
MERCURY MARQUIS |
7.0 428/ 429ci V8/ 6.4L 390ci V8 |
|
|
|
| |
1969-71
FORD LTD |
7.0 428/ 429ci V8/ 6.4L 390ci V8 |
|
|
|
| |
1969-71
FORD GALAXIE |
7.0 428/ 429ci V8/ 6.4L 390ci V8 |
|
|
|
| |
1969-71
FORD COUNTRY SQUIRE |
7.0 428/ 429ci V8/ 6.4L 390ci V8 |
|
|
|
| |
1969-71
FORD COUNTRY SEDAN |
7.0 428/ 429ci V8/ 6.4L 390ci V8 |
|
|
|
| |
1971
MERCURY COUGAR/XR-7 |
7.0L/429 ci/V8 |
|
|
|
| |
1970-71
LINCOLN CONTINENTAL |
7.5L/460CI/V8 |
|
|
|
| |
1969-71
MERCURY COLONY PARK |
7.0 429ci V8/ 6.4L 390ci V8 |
|
|
|
| |
1970 FORD
FAIRLANE |
7.0L/429 ci/V8 |
|
|
|
| |
1970-71
FORD GRAN TORINO |
7.0 429ci V8/ 5.0L 302ci V8 |
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
