Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
19 1/4" x 25 7/8" |
26" x 29 1/2" |
In - Passenger, Out - Passenger |
In - 1 1/2", Out - 1 3/4" |
Yes |
1/8-27 NPT |
28 1/2" |
Brackets |
|
|
Application |
Engines |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1968 - 1979
F-100 |
3.9L 240ci L6, 4.9L 300ci L6 |
|
2 1/2" |
2 7/8" |
|
1975 - 1979
F-150 |
3.9L 240ci L6, 4.9L 300ci L6 |
|
|
1968 - 1979
F-250 |
3.9L 240ci L6, 4.9L 300ci L6 |
|
|
1968 - 1979
F-350 |
3.9L 240ci L6, 4.9L 300ci L6 |
|
|
|
|
|
|
|
|
|
|
|
