CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

TRANS COOLER

Fill Neck

Mounting Specs

Mounting Type

16 1/4" x 24 3/4"

21 1/2" x 28"

In - Passenger, Out - Passenger

In - 1 1/2, Out - 1 3/4

1/2-20 Straight Thread, Inverted Flare

Yes

26 7/8"

Brackets

Application

Engines

NOTE: WILL FIT ALL #289 APPLICATIONS BUT WILL NOT MOUNT FACTORY SHROUD

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

1963 - 1965 Chevrolet Bel Air

3.8L 230ci L6, 4.1L 250ci L6,

B CORE 2 1/2"

2 3/4"

4.6L 283ci V8, 5.3L 327ci V8

1960 - 1965 Chevrolet Biscayne

3.8L 230ci L6, 3.9L 236ci L6,

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

4.1L 250ci L6, 4.6L 283ci V8

1 1/2"

2 1/2"

5.3L 237ci V8

1964 - 1965 Chevrolet Chevelle

3.2L 194ci L6, 3.8L 230ci L6,

4 ROW CORE THICKNESS

4 ROW TANK THICKNESS

4.6L 283ci V8, 5.3L 327ci V8

2 3/4"

3 1/8"

1959 - 1965 Chevrolet El Camino

3.2L 194ci L6, 3.8L 230ci L6,

4.6L 283ci V8, 5.3L 327ci V8

1959 - 1963 Chevrolet Impala

3.8L 230ci L6, 4.6L 283ci V8,

5.3L 327ci V8

1959 - 1961 Cheverolet Kingswood

3.8L 230ci L6, 4.6L 283ci V8
