CORE DIM (H x W)

OVERALL (H x W)

MOUNTING TYPE

BRACKET SPECS

HOSE LOCATIONS

HOSE FITTINGS

TRANS COOLER

17 x 26 1/4

18 1/4 x 31 5/8

Saddle Mount

N/A

In - Driver / Out Passenger

In 1-1/2 - Out 1-1/2

1/2-20 Straight Thread, Inverted Flare

BUICK APPLICATION

ENGINES

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

Buick Apollo - 1975

4.1l L6, 350ci V8

2 1/4"

2 1/2"

Buick Century - 1977

305ci v8

Buick Century - 1978

3.2l V6, 3.8l V6

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

Buick Century - 1979

3.2l V6, 3.8l V6, 301ci V8

1 1/2"

2 1/2"

Buick Century - 1980

265ci V8, 301ci V8, 305ci V8

Buick Century - 1981

265ci V8, 267ci V8, 305ci V8, 350ci V8

4 ROW CORE THICKNESS

4 ROW TANK THICKNESS

Buick LeSabre - 1980

301ci V8

2 3/4"

3 1/8"

Buick Regal - 1978

3.2l V6, 3.8l V6, 305ci V8

Buick Regal - 1979

3.2l V6, 3.8l V6, 301ci V8, 305ci V8

Buick Regal - 1980

301ci V8, 305ci V8

Buick Regal - 1981

4.4l V6, 4.4l V6

Buick Regal - 1982

4.4l V6, 305ci V8

Buick Regal - 1983-85

305ci V8

Buick Regal - 1986-87

305ci V8, 307ci V8

Buick Skylark - 1975

3.8l V6, 260ci V8, 350ci V8

Buick Skylark - 1976-79

3.8l V6, 260ci V8, 350ci V8

CADILLAC APPLICATION

ENGINES

Cadillac Seville - 1976-79

350ci V8

CHEVY APPLICATION

ENGINES

Chevy Blazer/Jimmy - 1973

4.1l L6, 4.8l L6

Chevy Blazer/Jimmy - 1974-79

4.1l L6

Chevy Blazer/Jimmy - 1980

4.1l L6, 305ci V8, 350ci V8

Chevy Camaro - 1970-71

4.1l L6, 307ci V8, 350ci V8

Chevy Camaro - 1972-73

307ci V8, 350ci V8

Chevy Camaro - 1974

350ci V8

Chevy Camaro - 1975

4.1l L6, 350ci V8

Chevy Camaro - 1976-79

4.1l L6, 305ci V8, 350ci V8

Chevy Camaro - 1980-81

267ci V8, 305ci V8, 350ci V8

Chevy Caprice - 1980-85

305ci V8, 350ci V8

Chevy Caprice - 1986

305ci V8, 307ci V8, 350ci V8

Chevy C/K Series - 1973-79

4.1l L6, 4.8l L6

Chevy C/K Series - 1980

4.1l L6, 4.8l L6, 305ci V8, 350ci V8

Chevy El Camino/Cabellero - 1978-79

3.3l V6, 3.8l V6, 305ci V8, 350ci V8

Chevy El Camino/Cabellero - 1980-82

267ci V8, 305ci V8

Chevy El Camino/Cabellero - 1983

305ci V8

Chevy El Camino/Cabellero - 1984-87

305ci V8

Chevy Impala - 1980-85

305ci V8, 350ci V8

Chevy Malibu - 1978

3.3l V6, 3.8l V6, 305ci V8,350ci V8

Chevy Malibu - 1979

3.3l V6, 3.8l V6 267ci V8, , 305ci V8,350ci V8

Chevy Malibu - 1980

267ci V8, 305ci V8, 350ci V8

Chevy Malibu - 1982

267ci V8, 305ci V8

Chevy Malibu - 1983

305ci V8

Chevy Monte Carlo - 1978

3.3l V6, 3.8l V6, 305ci V8

Chevy Monte Carlo - 1979

3.3l V6, 3.8l V6, 267ci V8, 305ci V8

Chevy Monte Carlo - 1980-82

267ci V8, 305ci V8

Chevy Monte Carlo - 1983-87

305ci V8

Chevy Nova - 1975-79

4.1l L6, 262ci V8, 350ci V8

Chevy S/T series - 1973

4.1l L6, 4.8l L6

Chevy S/T series - 1974-79

4.1l L6

Chevy S/T series - 1980

4.1l L6, 305ci V8, 350ci V8

Chevy Suburban - 1976-78

305ci V8, 350ci V8

Chevy Suburban - 1979-80

350ci V8

OLDS APPLICATION

ENGINES

Olds 98 - 1977-80

350ci V8

Olds Cutlass - 1978-79

3.8l L6, 260ci V8, 305ci V8, 350ci V8

Olds Cutlass - 1980

260ci V8, 305ci V8, 350ci V8

Olds Cutlass - 1981

260ci V8, 267ci V8

Olds Cutlass - 1982

Engines

Olds Cutlass - 1983

Not

Olds Cutlass - 1984

Listed

Olds Cutlass - 1985-87

305ci V8, 307ci V8

Olds Cutlass Calais - 1978-79

305ci V8

Olds Cutlass Calais - 1980

3.8l LV6, 260ci V8, 305ci V8, 350ci V8

Olds Cutlass Calais - 1981

260ci V8

Olds Cutlass Calais - 1982

267ci V8, 307ci V8

Olds Cutlass Calais - 1983

307ci V8

Olds Cutlass Calais - 1984

305ci V8, 307ci V8

Olds Cutlass Cruiser - 1978-79

3.8l V6, 260ci V8, 305ci V8, 350ci V8

Olds Cutlass Cruiser - 1980-81

260ci V8, 305ci V8, 350ci V8

Olds Cutlass Cruiser - 1982

260ci V8, 267ci V8, 305ci V8, 307ci V8

Olds Cutlass Cruiser - 1983

305ci v8, 307ci V8

Olds Cutlass Supreme - 1978-79

3.8l V6, 260ci V8, 305ci V8, 350ci V8

Olds Cutlass Supreme - 1980

260ci V8, 305ci V8, 350ci V8

Olds Cutlass Supreme - 1981

260ci V8, 350ci V8

Olds Cutlass Supreme - 1982

260ci V8, 267ci V8, 307ci V8

Olds Cutlass Supreme - 1983

305ci V8, 307ci V8

Olds Cutlass Supreme - 1988

307ci V8

Olds Delta 88 - 1980

260ci V8

Olds Eighty Eight/Royal - 1980

260ci V8

Olds Omega - 1975-76

4.1l L6, 350ci V8

Olds Omega - 1977-79

3.8l V6, 305ci v8, 350ci V8

PONTIAC APPLICATION

ENGINES

Pontiac Bonneville - 1980

3.8l V6

Pontiac Bonneville - 1981

265ci V8

Pontiac Bonneville - 1983-86

305ci V8

Pontiac Catalina - 1965-66

ALL

Pontiac Catalina - 1980

3.8l V6

Pontiac Catalina - 1981

265ci V8

Pontiac Grand Am - 1978

301ci V8, 305ci V8

Pontiac Grand Am - 1979

3.8l V6, 301ci V8, 305ci V8

Pontiac Grand Am - 1980

301ci V8, 305ci V8

Pontiac Grand Le Mans - 1975

4.1l L6, 350ci V8, 400ci V8, 455ci V8

Pontiac Grand Le Mans - 1976

4.1l L6, 260ci V8, 305ci V8, 350ci V8, 400ci V8, 455ci V8

Pontiac Grand Le Mans - 1977

3.8l V6 4.1l L6, 301ci V8, 305ci V8, 350ci V8, 400ci V8, 403ci V8

Pontiac Grand Le Mans - 1978

3.8l V6, 305ci v8, 350ci V8

Pontiac Grand Le Mans - 1979-80

3.8l V6, 301ci V8, 305ci v8, 350ci V8

Pontiac Grand Prix - 1978-79

3.8l V6, 301ci V8, 305ci V8

Pontiac Grand Prix - 1980-81

265ci V8, 301ci V8, 305ci V8

Pontiac Grand Prix - 1983-86

305ci V8

Pontiac Le mans - 1978

3.8l V6, 305ci v8, 350ci V8

Pontiac Le mans - 1981

3.8l V6, 265ci V8, 301ci V8, 305ci V8

Pontiac Parisienne - 1984-85

305ci V8

Pontiac Parisienne - 1986

305ci V8, 307ci V8

Pontiac Pheonix - 1978-79

3.8l V6, 305ci V8

Pontiac Ventura - 1975-76

4.1l L6, 350ci V8

Pontiac Ventura - 1977

3.8l V6, 301ci V8
