CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
TRANS COOLER |
MOUNTING TYPE |
BRACKET SPECS |
| |
13 3/4 x 23 1/4 |
19 3/4 x 27 1/4 |
In - Driver, Out - Passenger |
In - 1 1/4, Ou t- 1 1/4 |
Metric 14-1.5 |
Bracket Mount |
Vert - 8 7/8 Horizontal- 26 1/2 |
| |
|
|
|
|
|
|
|
| |
APPLICATION |
ENGINES |
|
|
|
2 ROW CORE THICKNESS |
2 ROW TANK THICKNESS |
| |
1970-1973 Datsun 240z |
2.4 L6, 2.6 L6, 2.8 L6, 3.1 |
|
|
|
1 1/2" |
2 3/4" |
| |
1974-1975 Datsun 260z |
2.4 L6, 2.6 L6, 2.8 L6, 3.1 |
|
|
|
|
|
| |
|
|
|
|
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
| |
|
|
|
|
|
2 1/4" |
2 3/4" |
| |
|
|
|
|
|
|
|
| |
|
|
|
|
|
4 ROW CORE THICKNESS |
4 ROW TANK THICKNESS |
| |
|
|
|
|
|
2 3/4" |
3 1/8" |
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
