CORE DIM (H x W)	OVERALL (H x W)	HOSE LOCATIONS	HOSE FITTINGS	FILL NECK	TRANS COOLER	MOUNTING TYPE	BRACKET SPECS
	16 3/4 x 22 1/4	20 3/4 x 25 1/2	In - Passenger, Out - Passenger	In - 1 1/2, Out - 1 1/2	Yes	Metric 12-1.5	Bracket Mount	Vert - 7 1/2, Horizontal - 24 1/8
	APPLICATION		ENGINES				3 ROW CORE THICKNESS	3 ROW TANK THICKNESS
	Mazda RX-7 1983-85		1.1, 1.3, R2				2"	2 3/4"
