CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
Fill Neck |
TRANS COOLER |
MOUNTING TYPE |
|
|
11 1/8 x 31 |
12 3/4 x 35 1/2 |
In - Passenger, Out - Driver |
In - 1 1/4, Out - 1 1/2 |
No |
5/8-18 Straight Thread, Inverted Flare |
Pin Mount |
|
|
|
APPLICATION |
ENGINE |
|
2 ROW CORE THICKNESS |
2 ROW TANK THICKNESS |
|
|
1984 - 1990
Jeep Cherokee |
2.8L 173ci V6. 4.0L 242ci In-Line 6 |
|
1 1/2" |
2 1/2" |
|
|
1987 - 1990
Jeep Comanche |
4.0L 242ci In-Line 6 |
|
|
1984 - 1990
Jeep Wagoneer |
2.8L 173ci V6. 4.0L 242ci In-Line 6, 4.6L 282ci In-Line 6 |
|
|
See Part Number 1193 for Open System
Conversions |
|
|
|
|
|
|
|
|
|
|
|
|
|
