CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
TRANS COOLER |
FILL NECK |
MOUNTING TYPE |
BRACKET SPECS |
|
17 3/8 x 22 3/4 |
22 3/4 x 24 3/8 |
In - Passenger, Out - Driver |
In - 1 1/2", Out - 1 3/4" |
1/8-27 NPT |
Yes |
Bracket |
23 7/8" |
|
|
|
|
|
|
|
|
|
|
APPLICATION |
Engine |
|
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
1967 Ford
Galaxie Base |
5.8L 352ci V8, 6.4L 390ci V8, 7.0L 428ci V8 |
|
|
2" |
2 3/8" |
|
1967 Ford
Custom Base |
5.8L 352ci V8, 6.4L 390ci V8, 7.0L 428ci V8 |
|
|
1967 Ford
LTD Base |
5.8L 352ci V8, 6.4L 390ci V8, 7.0L 428ci V8 |
|
4 ROW CORE THICKNESS |
4 ROW TANK THICKNESS |
|
2 3/4" |
3 1/8" |
|
|
|
|
|
|
|
|
|
