Core Dim (H x W)	Overall (H x W)	Hose Locations	Hose Fittings	Fill Neck	Trans Cooler	Bracket	Mounting Type
	17 1/8" x 21 5/8"	22 3/8" x 25 5/8"	In - Left Center, Out - Driver	In - 1 1/2", Out - 1 1/2"	Yes	1/8-27 NPT	24 3/8"	Brackets
	Application		Engines				3 Row Core Thickness	3 Row Tank Thickness
	1965 -1966 Dodge Dart		4.5L 273ci V8				2"	Upper - 3 1/2", Lower - 2 1/2"
	1965 - 1966 Plymouth Valiant		4.5L 273ci V8
	1966 Plymouth Barracuda		4.5L 273ci V8
