Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 3/8" x 22 3/4" |
22 1/8" x 24 1/4" |
In - Passenger, Out - Driver |
In - 1 1/2", Out - 1 3/4" |
Yes |
1/8-27NPT |
23 3/4" |
Brackets |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1965 - 1966
Ford Custom |
5.8L 352ci V8, 6.4L 390ci V8, 7.0 427ci v8 |
|
|
2 1/4" |
2 1/2" |
|
1965 - 1966
Ford Custom 500 |
5.8L 352ci V8, 6.4L 390ci V8, 7.0 427ci v8 |
|
|
|
|
|
1965 - 1966
Ford Galaxie |
5.8L 352ci V8, 6.4L 390ci V8, 7.0 427ci v8 |
|
|
4 Row Core Thickness |
4 Row Tank Thickness |
|
1965 - 1966
Ford Galaxy 500 |
5.8L 352ci V8, 6.4L 390ci V8, 7.0 427ci v8 |
|
|
2 3/4" |
3 1/8" |
|
1965 - 1966
Ford LTD |
5.8L 352ci V8, 6.4L 390ci V8, 7.0 427ci v8 |
|
|
|
|
|
1966 Ford
Fairlane |
6.4L 390ci V8 |
|
|
|
|
|
1966
Mercury Comet |
6.4L 390ci V8 |
|
|
|
|
|
1966
Mercury Cyclone |
6.4L 390ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
