CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
FILL NECK |
TRANS COOLER |
MOUNTING TYPE |
|
17 1/2" x 23 5/16" |
20" x 27 3/4" |
In - Passenger, Out - Driver |
In - 1 3/4", Out - 1 3/4" |
No |
1/4-18 NPT |
Bracket |
|
|
|
|
|
|
|
|
|
APPLICATIONS |
ENGINE |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1964 -1966
Ford Thunderbird |
6.4L 390ci V8, 7.0L 427ci V8, 7.0L 428ci V8 |
|
2" |
2 1/4 |
|
|
|
|
|
|
|
|
|
Notes: |
2 radiators available for late 66 cars. Please check core dimensions
and top plate. |
|
4 Row Core Thickness |
4 Row Tank Thickness |
|
|
|
|
|
|
2 3/4" |
3 1/8" |
|
|
|
|
|
|
|
|
|
