Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
20 1/2" x 24" |
26" x 28
1/8" |
In - Driver, Out -
Passenger |
In - 1 1/2",
Out - 1 3/4" |
Yes |
1/2 20 Straight
Thread, Inverted Flare |
27 1/4" |
Bracket |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1957 Oldsmobile 88 |
6.1L 371ci V8 |
|
|
|
2" |
Upper - 3
1/8", Lower 2 1/2" |
|
1957 - 1958 Oldsmobile 98 |
6.1L 371ci V8 |
|
|
|
|
|
|
1958 Oldmobile Dynamic |
6.1L 371ci V8 |
|
|
|
|
|
|
1957 - 1958 Oldsmobile Fiesta |
6.1L 371ci V8 |
|
|
|
|
|
|
1957 Oldsmobile Golden Rocket 88 |
6.1L 371ci V8 |
|
|
|
|
|
|
1957 Oldsmobile Starfire |
6.1L 371ci V8 |
|
|
|
|
|
|
1957 - 1958 Oldsmobile Super 88 |
6.1L 371ci V8 |
|
|
|
|
|
|
NOTE: Designed for Chevy Engine Conversion |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
