Core Dim (H x W)
Overall (H x W)
Hose Locations
Hose Fittings
Fill Neck
Trans Cooler
Mounting Specs
Mounting Type
18 1/2" x 18 3/8"
25 1/4" x 23"
In - Passenger, Out - Driver
In - 1 1/2", Out - 1 3/4"
Yes
1/8-27 NPT
21 7/8"
Brackets
Application
Engines
3 Row Core Thickness
3 Row Tank Thickness
1954 Mercury Custom
4.2L 256ci V8
B Core 2 1/2"
Upper - 3 1/4", Lower - 2 3/4"
1954 Mercury Monterey
4.2L 256ci V8
