Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
22" x 22" |
27 7/8" x 24
1/8" |
In - Center, Out -
Passenger |
In - 1 3/4",
Out - 1 3/4" |
Yes |
N/A |
23 1/4" |
Brackets |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1950 - 1954 Pontiac Catalina |
3.9 239ci L6, 4.4L
268 L8 |
|
|
|
2 1/2" |
Upper - 3
1/4", Lower 2" |
|
1949 - 1954 Pontiac Chieftan |
3.9L 239ci L6, 4.1L 249ci L8 |
|
|
|
|
|
|
4.4L 268ci L8 |
|
|
|
|
|
|
1949
- 1952 Pontiac Silver Streak |
3.9L 239ci L6, 4.1L 249ci L8 |
|
|
|
|
|
|
4.4L 268ci L8 |
|
|
|
|
|
|
1954 Pontiac Star Cheif |
4.4L 268 L8 |
|
|
|
|
|
|
1949 - 1952 Pontiac Streamliner |
3.9L 239ci L6, 4.1L 249ci L8 |
|
|
|
|
|
|
4.4L 268ci L8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
