CORE DIM (H x W)	OVERALL (H x W)	HOSE LOCATIONS	HOSE FITTINGS	Fill Neck	TRANS COOLER	MOUNTING TYPE
	19 1/8 x 19 1/2	26 1/2 x 23 3/4	In -  Driver, Out - Passenger	In - 1 1/2 Out - 1 3/4	Yes	1/2-20 Straight Thread, Inverted Flare	Flanges
	APPLICATION		ENGINES			3 ROW CORE THICKNESS	3 ROW TANK THICKNESS
	1942-48 Ford Coupe		w/ Chevy Configuration			2 1/4"	3 1/8"
	1942-48 Mercury Coupe 29A		w/ Chevy Configuration
						2 ROW CORE THICKNESS
						1 1/2"
						4 ROW CORE THICKNESS	4 ROW TANK THICKNESS
						2 3/4"	3 1/8"
